SkySpec 2D Instrument v.250
TELESCOPE-SPECTROMETER SYSTEM for PASSIVE REMOTE SENSING
· Telescope-spectrometer system for direct-sun and scattered skylight spectrum acquisition
· Optimized for UV/Vis-aerosol and trace gas remote sensing with the DOAS method
· Other applications are possible
· Detectable gases: NO2, HCHO, SO2, O4, O3, H2O, HONO, Glyoxal, BrO, IO, ...
· Modular and customizable to meet your specific requirements
· Software packages for spectral analysis, post-processing and data visualization available
SPECTROMETER:
· Grating spectrometer in compact and rugged enclosure
· Characterized and calibrated
· Active temperature stabilization
· Low straylight design
· Sub-nm spectral resolution
· High spectral sampling
· Homogenized slit illumination
· Available with backthinned CCD detector to maximize UV sensitivity
TELESCOPE: · Two motorized axes → automatic pointing to anywhere in the sky hemisphere · Automatic correction of telescope viewing elevation via integrated inclination sensor · Narrow field of view · Rugged and weather-proof design with minimum outside moving parts · Integrable wide angle cameras for monitoring purposes |  | |
